Description
750 KVA Three Phase Pad Mount, RC TYPE, Primary 11847Y/6840, Secondary 480/277V Reconditioned Transformer
Product Specifications:
Product Type: Reconditioned
Transformer Type: Pad Mount
KVA: 750
Phase: 3
High Voltage: 11847Y/6840
Low Voltage: 480Y/277
Taps: W/TAPS 2 X 2 1/2% +/-
5.90% imp
Weight:6,770 lbs
Dimensions: 66″ High 52″Deep 85″ Wide
Accessories:
Primary Bushings, Dead Front, Radial Feed
8.3/14.4 KV Wells with Inserts
Bayonet Fusing
Secondary Bushings, St. Stud Connections w/Spades
Oil Level Gauge
Temperature Gauge
Pressure/Vacuum Gauge
Pressure Relief Device
Pentahead Entry Assembly
Mineral Oil (standard)
Non-PCB Label
Drain Valve with Sampler
Bell Green Paint
Undercoating
Warranty: 36 Month Guarantee
*FOR ADDITIONAL INFORMATION, PLEASE EMAIL US.
