Name: ATC Diversified Electronics SLU-100-ASA 10/240VAC 8-Pin Phase Monitoring Relay
SKU: SLU-100-ASA
Availability: InStock

ATC Diversified Electronics SLU-100-ASA 10/240VAC 8-Pin Phase Monitoring Relay

$166.95

The popular ATC-Diversified Electronics SLU Series Universal Phase Monitors provide cost-effective protection against premature equipment failure caused by voltage faults on 3-phase systems (Delta or Wye). A single SLU Phase Monitoring Relay can be easily adjusted for the voltage, percent unbalance and fault delay requirements to protect against unbalanced voltages or single-phasing on applications up to 700 VAC.

SKU # : SLU-100-ASA

List Price : $176.95

In stock

Compare

Description

ATC Diversified Electronics SLU-100-ASA 10/240VAC 8-Pin Phase Monitoring Relay

Product Description:

Brand: ATC Diversified Electronics

Part Number: SLU-100-ASA

Contact Form: SPDT

Current Rating: 10 A

Function: Phase Monitor

Monitoring Function: Phase Monitor

Mounting Type: Socketable

Number of Pins: 8

Operating Temperature: 0 to +55 °C

Primary Type: Monitoring Relays

Relay Type: Electromechanical

Series: SLU Series

Special Features: Automatic or Manual Reset, Phase Unbalance: 2% to 10%, Adjustable

Standards: CUL, UL

Supply Voltage: 550 VAC

Termination: 8-Pin Octal

Voltage Rating: 240 V

Fault Delay: 0.1 to 25 Sec, Adjustable

Restart: 0.5 to 300 Sec, Adjustable (Auto Restart)

Relay Rating: 10 A @ 240 VAC

UL and Canadian UL Listed
