Description
Loren Cook D1100 Shaded Pole Condenser Fan Motor
Product Specifications:
Brand: Loren Cook
Part Number: D1100
Item: Condenser Fan Motor
Motor Design: Shaded Pole
Phase: 1
HP: 1/50
No. of Speeds: 2
Voltage: 115
Motor Shaft Rotation: CWSE
Frame: Non-Standard
Motor Enclosure Design: Open Air-Over
Motor Mounting Type: Stud
Shaft Dia.: 5/16″
Shaft Length: 2-3/8″
Number of Shafts: 1
Motor Thermal Protection: Auto
Nameplate RPM: 1550/900
Motor Application: OEM Replacement
Motor Sub Application: Condenser Fan
Full Load Amps: 1.2/0.70
Hz: 60/50
Ins. Class: B
Max. Ambient Temp.: 40 Degrees C
Motor Service Factor: 1
Motor Bearings: Sleeve
Motor Shaft Design: Flat
Body Dia.: 3-19/64″
Length Less Shaft: 2-13/16″
Overall Length: 5-3/16″
Bolt Circle Dia.: 2-13/16″
Mounting Stud Pattern: 4″ x 4″
Stud Size: 8-32 X 7/8″
Capacitor Required: No
Application: Fans and Blowers
