Description
Keystone KT-LED22T5HO-48G Series 22W T5 LED Tube Lamp
Product Specifications:
Brand: Keystone
Part Number: KT-LED22T5HO-48G-835-E / KT-LED22T5HO-48G-840-E / KT-LED22T5HO-48G-850-E
Lamp Type: Linear
Bulb Type: T5 LED
Base Type: G5
Dimming Type: 0–10V
Lumens: 3200-3400
Efficacy: 128/132/136 Lm/W
Wattage: 22W
Lamp Input Voltage: 36–45Vdc
Color Temperature: 3500K/4000K/5000K
CRI: >82
BEeam Angle: 240º
Visible Light Area: 325º
UL Type C LED tubes, powered by Keystone Type C LED drivers
UL Classified Std. 1598C
Glass construction with metal end caps
Operating temperature: –20ºC/–4ºF to 45ºC/113ºF
THD <15% at full driver load
PF >0.90 at full driver load
0 –10V dimmable
50,000+ hours lifetime
Keystone tube and driver pairing wires either single-ended or double-ended. See wiring diagrams for details and common ballast retrofit scenarios
Low optical flicker
5-year warranty
