Keystone KTLD-40-UV-1100-VDIM-L2 40W Constant Current LED Driver
Product Specifications:
Brand: Keystone
Part Number: KTLD-40-UV-1100-VDIM-L2
Constant current LED driver
Total power: 40W
Input Voltage: 120~277Vac ± 10%
Output Current: 1100mA
Output Voltage: 18-36V
Efficiency: 81%
Operating Temperature: -30 to 60°C
Storage Temperature: -40 to 85°C
Frequency: 50/60Hz
Max input current: 0.41A @120V and 0.19A @ 277V
THD: <20%
Protection: Over voltage, Over current and Short circuit
Withstand voltage: I/P – O/P 2k Vac
Humidity: 5% to 95%
Power factor: >0.9 @full load, 120V through 277V
MTBF: 384,000 hours at 40°C ambient (~70°C Case temp)
Inrush current: 20A @230V
Maximum case Temperature: 90°C
Standards: UL 8750 Listed, UL/cUL Listed, FCC 47 CFR Part 15, Class B EN61000-3-2 Compliant, RoHS Compliant
5-year warranty
