Description
Keystone KTLD-50-UV-2X500-VDIM-L5 50W Dual Channel Constant Current LED Driver
Product Specifications:
Brand: Keystone
Part Number: KTLD-50-UV-2X500-VDIM-L5
Dual-Channel Constant Current LED driver
Total power: 50W
Input Voltage: 120~277Vac ± 10%
Frequency: 50/60 Hz
Output Current: 500mA
Dimming: 0-10V
Output Voltage: 25-50V
Efficiency: 82%
Power Factor: > 0.9 @full load, 120V through 277V
Inrush Current: 20A @230V
Max. Input Current: 0.56A @120V, 0.26A @277V
THD: < 20%
Withstand Voltage: Input to output, 2K VAC
Protection: Over voltage, Over current and Short circuit
Operating Temperature: -30 to 50°C
Storage Temperature: -40 to 85°C
Humidity: 5% to 95%
MTBF: 440,000 hours at 40°C ambient (~70°C Case temp)
Life Rating: 76,000 hours at 120Vac input, 100% load and 60ºC case temperature
Maximum Case Temperature 80°C
Standards: UL 8750 Listed, UL/cUL Listed, FCC 47 CFR Part 15, Class A Consumer Limit EN61000-3-2 Compliant
5-year warranty
