Description
Keystone KTLD-75-UV-1450-VDIM-L5 75W Constant Current LED Driver
Product Specifications:
Brand: Keystone
Part Number: KTLD-75-UV-1450-VDIM-L5
Constant Current LED driver
Total power: 75W
Output Current: 1450mA
Output Voltage: 27-51V
Max Current: 0.75@ 120V; 0.35 @ 277V
Efficacy: 86%
Input Voltage Range 120~277Vac ± 10%
Frequency 50/60 Hz
Power Factor > 0.9
Meets FCC Part 15 (Class B) Consumer Limits
Short Circuit, Over Current, and Over Temperature Protection
Type 1 Outdoor, Suitable for Dry and Damp Locations
UL 8750 Pending, Type TL Pending
Maximum Case Temperature: 194ºF/90ºC
Operating Temperature: -22-140ºF/-30-60ºC
Class 2 Output
Dimmable with 0-10V Dimmer
THD < 20%
5-year warranty
