Brand: Lex PowerHOUSE™
Part Number: PH100W-NDC-15CC-RCAT
Rating: 100 Amp, Single-phase (H,N,G), 2-pole, 3-wire, 125 VAC, 60 Hz
Environmental Rating:     NEMA Type 1 (Indoor Use)
Input:  (1) Stage Pin (Bates), 100 Amp, 2-pole, 3-wire, 125 VAC inlet, panel mount
Feed Thru: Yes
Main Breaker:     None
Output: (5) NEMA 5-20 (Edison), 20 Amp, 2-pole, 3-wire, 125 VAC, straight blade duplex receptacles, panel mount; (4) USB Type A, 4.2 Amp, 2-pole, 3-wire, 125 VAC 4-port receptacles, panel mount
Overcurrent Protection: (5) 20 Amp, 125 VAC, single-pole, hydraulic magnetic, branch-rated circuit breakers
Data Input:     Wired 5-Pin XLR Inlet, DMX512/RDM
Data Feed Thru: Yes
Data Output: (5) Optically Isolated 5-Pin XLR Receptacles
Enclosure Type: LOpSter™
Dimensions: 10.25”W x 11.50”H x 8.00”D
Weight: 13.5 lbs
Markets Served: Theatrical, Motion Picture, Television Production

– The LOpSter Trap combines the function of electrical power “lunch boxes” with the data distribution of an “opto-splitter”, both of which are typically found in studios and on locations
– One box to inventory, transport, set up and strike as opposed to two
– Reliable DMX512/RDM Splitter/Repeater that processes communication protocols with a high degree of reliability
– 4.2A 4-Port USB Type-A Outlet Charger Receptacle for convenient powering of electronics
– Hydraulic magnetic breakers will not nuisance trip at higher temperatures and are mounted flush for easy access and circuit identification
– Brightly colored receptacles increase visibility in low-light situations
– Threaded inserts for brackets provide easy mounting of C-Clamps
– Pairing with the Lex PowerDataTM Cable greatly increases labor savings
