Description
Lex PH200A3-N1J-16DW-T 200 Amp Terrapin Station II™ to 50 Amp Locking Receptacles, Weather Resistant
Product Specifications:
Brand: Lex PowerHOUSE™
Part Number: PH200A3-N1J-16DW-T
Rating: 200 Amp, 3 Phase (H,H,H,N,G), 4-Pole, 5-Wire, 120/208Y VAC
Environmental Rating: NEMA Type 3R (Weather Resistant)
Input: (1) set of (5) 16 Series Cam-type, 400 Amp, single pole, 600V, color-coded inlets, panel mount
Output: (6) 50 Amp, 3-Pole, 4-Wire, 125/250 VAC, California-style locking receptacles
Feed Thru: None
Main Breaker: None
Overcurrent Protection: (6) 50 Amp, 125 VAC, double pole, hydraulic magnetic, branch-rated circuit breakers
Dimensions: 14.25″ x 14.25″W x 17.50″H
Weight: 35.0 lbs
Agency Approval: cULus Listed
Markets Served: Electrical Distribution, Maintenance, Shipbuilding, Generator Rental, Construction, Outdoor Events, Shelters
Part Number: PH200A3-N1J-16DW-T
Rating: 200 Amp, 3 Phase (H,H,H,N,G), 4-Pole, 5-Wire, 120/208Y VAC
Environmental Rating: NEMA Type 3R (Weather Resistant)
Input: (1) set of (5) 16 Series Cam-type, 400 Amp, single pole, 600V, color-coded inlets, panel mount
Output: (6) 50 Amp, 3-Pole, 4-Wire, 125/250 VAC, California-style locking receptacles
Feed Thru: None
Main Breaker: None
Overcurrent Protection: (6) 50 Amp, 125 VAC, double pole, hydraulic magnetic, branch-rated circuit breakers
Dimensions: 14.25″ x 14.25″W x 17.50″H
Weight: 35.0 lbs
Agency Approval: cULus Listed
Markets Served: Electrical Distribution, Maintenance, Shipbuilding, Generator Rental, Construction, Outdoor Events, Shelters
Features:
– Circuit breakers are mounted under hinged lid for enhanced safety
– Weather-protective receptacle covers
– Stackable and compact for easy storage and portability
– Heavy-duty aluminum legs, position the box at the NEC regulatory height of 6 inches while allowing for storage and transportation stacking
