Catalog Number: U2120-O-HSP
UPC: 784572292550
Length (IN): 6.5
Width (IN): 17.75
Height (IN): 31.75
Brand Name: Milbank
Type: Ringless Meter Socket
Application: Meter Socket
Standard: UL Listed;Type 3R
Voltage Rating: 600 Volts Alternating Current
Amperage Rating: 320 Continuous Ampere
Phase: 3 Phase
Frequency Rating: 60 Hertz
Size: 6.5L x 17.75W x 31.75H
Number Of Cutout: 0
Cutout Size: No Main Breaker
Cable Entry: Underground
Terminal: 3/8 Inch Stud
Insulation: Glass Polyester
Mounting: Surface Mount
Enclosure: G90 Galvanized Steel with Powder Coat Finish
Jaw Quantity: 7 Terminal
Bypass Type: Lever Bypass
Number of Meter Positions: 1 Position
Equipment Ground: Grounding Stud
Hub Opening: Plain Top
Number Of Receptacles: 0
