Catalog Number: U2855-X-HSP
UPC: 784572271852
Length (IN): 4.844
Width (IN): 31
Height (IN): 37
Brand Name: Milbank
Type: Ringless Meter Socket
Application: Meter Socket With Main
Standard: UL Listed;Type 3R
Voltage Rating: Up to 240 Volts Alternating Current
Phase: 1 Phase
Frequency Rating: 60 Hertz
Size: 4.844L x 31W x 37H
Cable Entry: Overhead or Underground
Terminal: 3/8 Inch Stud Line Side and Single, Mechanical Load Side
Insulation: Glass Polyester
Mounting: Surface Mount
Enclosure: G90 Galvanized Steel with Powder Coat Finish
AIC or SCCR Rating: Please Contact Factory
Optional Line Side Lug Kits:K1350
Optional 5th Terminal Position:9 O’Clock
Maximum Amperage:125 Maximum Ampere
Number of Jaws:4 Terminal
Hub Opening and Closing Plates:Large Closing Plate
Bypass Provision:No Bypass
Number Positions:5 Positions
