Catalog Number: U5890-X-2/200-HSP
UPC: 784572761070
Length (IN): 6
Width (IN): 24.5
Height (IN): 35
Brand Name: Milbank
Type: Ringless Meter Socket
Application: Meter Socket With Main
Standard: UL Listed;Type 3R
Voltage Rating: Up to 240 Volts Alternating Current
Amperage Rating: 320 Continuous Ampere
Phase: 1 Phase
Frequency Rating: 60 Hertz
Size: 6L x 24.5W x 35H
Number Of Cutouts: 2
Cutout Size: Two 200 Ampere Main Breakers
Cable Entry: Overhead and Underground and Side Wireway
Terminal: 3/8 Inch Stud
Insulation: Glass Polyester
Mounting: Surface Mount
Enclosure: G90 Galvanized Steel with Powder Coat Finish
Jaw Quantity: 4 Terminal
Bypass Type: Lever Bypass
Number of Meter Positions: 1 Position
Equipment: Ground 3 Barrel Ground Lug
Hub Opening: Large Closing Plate
Load Side Wire Range: 1 AWG – 300 kcmil
Number Of Receptacles: 0
