Catalog Number: U6266-XTL-100-HSP
UPC: 784572768888
Length (IN): 4.5
Width (IN): 14.125
Height (IN): 30
Brand Name: Milbank
Type: Ringless Meter Socket
Application: Meter Socket With Main
Standard: UL Listed;Type 3R
Voltage Rating: Up to 240 Volts Alternating Current
Amperage Rating: 200 Continuous Ampere
Phase: 1 Phase
Frequency Rating: 60 Hertz
Size: 4.5L x 14.125W x 30H
Number Of Cutouts: 1
Cutout Size: One 100 Ampere Main Breaker
Cable Entry: Overhead or Underground
Terminal: Single Mechanical
Insulation: Glass Polyester
Mounting: Surface Mount
Enclosure: G90 Galvanized Steel with Powder Coat Finish
Jaw Quantity: 4 Terminal
Bypass Type: No Bypass
Number of Meter Positions: 1 Position
Equipment Ground: Ground Bar
Hub Opening: Small Closing Plate
Line Side Wire Range: 6 AWG – 350 kcmil
Load Side Wire Range: 1 AWG – 300 kcmil
Number Of Receptacles: 0
