Catalog Number: UAP1254-X-HSP
UPC: 784572300743
Length (IN): 5.125
Width (IN): 42.688
Height (IN): 16
Brand Name: Milbank
Type: Ringless Meter Socket
Application: Meter Socket
Standard: UL Listed;Type 3R
Voltage Rating: 300 Volts Alternating Current
Amperage Rating: 200 Continuous Ampere
Phase: 1 Phase
Frequency Rating: 60 Hertz
Size: 5.125L x 42.688W x 16H
Number Of Cutouts: 0
Cutout Size: No Main Breaker
Cable Entry: Overhead or Underground with Center Wireway
Terminal: 3/8 Inch Stud
Insulation: Glass Polyester
Mounting: Surface Mount
Enclosure: Aluminum with Powder Coat Finish
Jaw Quantity: 4 Terminal
Bypass Type: No Bypass
Number of Meter Positions: 4 Positions
Equipment Ground: Ground Lug
Hub Opening: Large Closing Plate
Load Side Wire Range: 6 AWG – 350 kcmil
Number Of Receptacles: 0
