Description
Philips Lighting 913701235602 Electronic Ballast-4 F32T8 120V-277V
Product Specifications:
Brand: Philips
Part Number: 913701235602
Lamp Type: F32T8
Number of Lamps: 3/4 piece/unit
Ballast Type: Electronic Fluorescent
Suitable For Outdoor Use
Automatic Restart
Input Voltage: 120 to 277 V
Input Frequency: 50 to 60 Hz
Total Harmonic Distortion: 10 %
Ignition Method: Instant Start
Crestfactor (Nom): 1.6
Ignition Time (Nom): 0.1 s
Ballast Factor (Nom): 0.77
Power Factor (Nom): 0.98
Input Current (Max): 0.81 A
Input Current (Min): 0.35 A
Input Power (Nom): 96-94 W
Rated Lamp Power: 32 W
Wire Striplength: 0.50/0.375 mm
Lamp Connection: Parallel
Wire Gauge (Nom): 18AWG mm
Wire Type: Solid
Remote Wiring Configuration Allowed
Tandem Wiring Configuration Allowed
Through Wiring Configuration Allowed
Max Ballast-Lamp Distance Remote Wiring: ES = 6′ / Standard = 20′
Max Ballast-Lamp Distance Tandem Wiring: ES = 6′ / Standard = 20′
Max Ballast-Lamp Distance Through Wiring: ES = 6′ / Standard = 20′
