Catalog Number: U5200-XL
UPC: 784572258150
Length (IN): 5.188
Width (IN): 8.688
Height (IN): 64.5
Brand Name: Milbank
Type: Unmetered Power Supply Unit
Special Features: Small Closing Plate, 2 Barrel Ground
Lug and Ground Bar, No Bypass,
Single Power Head, 6 Branch Circuits
Application: RV Power
Standard: UL Listed
Voltage Rating: Up to 240 Volts Alternating Current
Amperage Rating: 125 Ampere Continuous
Wattage: Not Applicable
Frequency Rating: 60 Hertz
Phase: 1 Phase
Number of Receptacles:0
Control: No Main Breaker
Material: G90 Galvanized Steel with Powder Coat Finish
Mounting: Pedestal Mount
Cable Size: 6 AWG to 350 KCMIL
Enclosure: Type 3R
