Brand: Square D
Part Number: ATV212HU22N4
Device short name: ATV212
Product destination: Asynchronous motors
Phase: 3 phase
Motor power kW: 2.2 kW
Maximum Horse Power Rating: 3 hp
Supply voltage limits: 323…528 V
Supply frequency: 50…60 Hz – 5…5 %
Line current: 3.6 A 480 V / 4.6 A 380 V
Range of Product: Altivar 212
Product or Component Type: Variable speed drive
Product Specific Application: Pumps and fans in HVAC
Communication Port Protocol: BACnet, LonWorks, Modbus, METASYS N2, APOGEE FLN
Rated supply voltage: 380…480 V – 15…10 %
EMC filter: Class C2 EMC filter integrated
IP degree of protection: IP21
Apparent power: 3.9 kVA 380 V
Continuous output current: 5.1 A 380 V / 5.1 A 460 V
Maximum transient current: 5.6 A 60 s
Speed drive output frequency: 0.5…200 Hz
Speed range: 1…10
